Hoshizaki PA0613 OEM Water Pump Assembly

Manufacturer service update: PA0613 and SP-0613

Hoshizaki bulletin SB26-0003, dated February 5, 2026, states that the PA0613 manufacturer kit changes to SP-0613 beginning March 2026 and that the two manufacturer kits are interchangeable. It also identifies capacitor references 443192-03 and 4A6435-03 as interchangeable. Confirm which kit and components will be supplied; the existing store SKU is unchanged.

Hoshizaki PA0613 OEM Water Pump Assembly

The Hoshizaki PA0613 Water Pump Assembly is an OEM water-circulation component designed for compatible Hoshizaki commercial ice machines. The pump moves water through the applicable ice-making water system so the machine can maintain the circulation and distribution required during normal freeze-cycle operation.

Reliable water circulation is essential to consistent commercial ice production. A water pump that fails to start, operates intermittently, becomes restricted, develops mechanical wear, or no longer produces adequate water flow can contribute to poor water distribution, inconsistent ice formation, extended operating cycles, reduced ice production, or an interrupted ice-making sequence.

When qualified diagnosis confirms pump replacement is required, using the correct Hoshizaki OEM PA0613 helps restore the water-circulation configuration intended for compatible Hoshizaki equipment.

OEM Part Details

• Manufacturer: Hoshizaki
• OEM Part Number: PA0613
• MPN: PA0613
• SKU: PA0613
• Part Type: Water Pump Assembly
• Application: Commercial Ice Machines
• System: Ice Machine Water Circulation System
• Function: Water Circulation & Distribution

Compatible Hoshizaki Models

The Hoshizaki PA0613 OEM Water Pump Assembly is listed for compatible Hoshizaki commercial ice machines including:

• B-500PF
• B-700PF
• KM-340MAH
• KM-340MWH
• KM-340MWJ
• KM-500MAH
• KM-500MRH
• KM-500MWH
• KM-501MWH
• KM-515MAH
• KM-515MAJ
• KM-515MRH
• KM-515MRJ
• KM-515MWH
• KM-515MWH-P
• KM-515MWJ
• KM-630MAH
• KM-650MAH
• KM-650MRH
• KM-650MRJ
• KM-650MWJ
• KM-900MAH
• KM-900MRH
• KM-900MRH3
• KM-900MWH
• KM-901MAH
• KM-901MAH-P
• KM-901MWH
• KM-901MWH-P
• KML-600MAH
• KMS-830MLH-3
• KMS-830MLJ
• URC-12F

Compatibility Note: Hoshizaki equipment can vary by serial number, auxiliary code, production date, electrical configuration, and factory revision. Always verify OEM part number PA0613, the complete equipment model, serial number, auxiliary code where applicable, original pump, mounting arrangement, and water connections before ordering.

What the Hoshizaki PA0613 Water Pump Does

The Hoshizaki PA0613 water pump circulates water through the applicable ice-machine water system during the ice-making process. Proper circulation allows water to reach the intended freezing area and supports the repeated movement of water required during normal machine operation.

Correct pump operation helps support:

• Consistent water circulation
• Proper water distribution
• Reliable water delivery to the freezing section
• Consistent ice formation
• Normal freeze-cycle operation
• Proper interaction with related water-system components
• Dependable commercial ice production

Common Signs of a Water Pump Problem

Qualified commercial ice-machine technicians may inspect the Hoshizaki PA0613 when troubleshooting conditions such as:

• Water pump does not start
• Pump operates intermittently
• Little or no water circulation is present
• Water flow is weaker than expected
• Water does not distribute correctly across the freezing section
• Pump produces abnormal noise
• Pump vibrates excessively
• Pump motor becomes unusually hot
• Ice formation is inconsistent
• Ice production is reduced
• Freeze cycle becomes abnormal or extended
• Electrical connections show signs of overheating
• Scale or debris restricts the pump or water path
• Water leaks are present around the pump or connected plumbing

These symptoms do not automatically confirm pump failure. Water-level problems, water inlet valve issues, restricted water passages, scale accumulation, water-distribution components, wiring, electrical controls, and other ice-machine conditions can produce similar symptoms. The complete water-circulation system should be diagnosed before replacing the pump.

Diagnosing a Hoshizaki Ice Machine With No Water Circulation

If water is present in the machine but is not circulating correctly, technicians should determine whether the PA0613 pump is receiving the required electrical input and whether the water path is free of restrictions.

Depending on the equipment configuration, diagnosis may include checking:

• Water level in the machine
• Electrical supply to the pump when commanded
• Pump motor operation
• Electrical connectors
• Associated wiring
• Pump inlet
• Pump outlet
• Water tubing and passages
• Water-distribution components
• Scale accumulation
• Debris or restrictions
• Machine control output

Testing the complete circulation system helps prevent unnecessary pump replacement when another component or restriction is responsible for the lack of water movement.

Weak Water Flow or Poor Water Distribution

A water pump can sometimes operate while still producing inadequate circulation. Weak water flow should be evaluated before assuming the pump assembly itself has completely failed.

Possible causes include:

• Scale buildup
• Restricted pump inlet
• Restricted pump outlet
• Debris in the water system
• Restricted tubing
• Blocked distribution components
• Low water level
• Mechanical pump wear
• Electrical supply problems

Proper diagnosis should determine whether the problem originates in the PA0613 pump or elsewhere in the machine's water-distribution system.

Abnormal Pump Noise or Vibration

A Hoshizaki water pump that becomes noticeably louder than normal or develops excessive vibration should be inspected. Abnormal operation can indicate mechanical wear, debris, mineral buildup, restricted water flow, loose mounting, or another water-system condition.

Inspect for:

• Mechanical binding
• Excessive vibration
• Loose mounting
• Foreign material
• Scale deposits
• Water starvation
• Damaged pump components
• Contact with surrounding components

Continuing to operate a mechanically compromised pump can eventually result in complete loss of circulation or additional equipment problems.

Water Pump vs. Water Inlet Valve

The water pump and water inlet valve perform different functions within a Hoshizaki commercial ice machine.

• Water Inlet Valve: Controls water entering the machine.
• Water Pump: Circulates water already present within the applicable ice-making system.

If the machine does not contain sufficient water because it is not filling correctly, the inlet system should be inspected. If water is present but does not circulate correctly, the PA0613 pump and water-distribution system become important diagnostic areas.

Water Pump vs. Water-Level Control Problem

Incorrect water level can also affect apparent pump performance. A pump cannot provide normal circulation if the machine does not contain the amount of water required by its operating sequence.

When diagnosing low or inconsistent flow, technicians may need to inspect:

• Float switch or water-level controls
• Water inlet valve
• Actual water level
• Water reservoir
• PA0613 pump operation
• Water distribution components
• Control-board response

Scale, Minerals & Water-System Maintenance

Commercial ice-machine pumps operate continuously in contact with water. Mineral deposits, scale, sediment, and debris can accumulate within the water system and interfere with normal circulation.

Technicians should inspect for:

• Scale around the pump
• Restricted water passages
• Mineral buildup
• Sediment
• Debris
• Restricted tubing
• Contaminated water-distribution components

Water-system cleaning and maintenance should follow applicable Hoshizaki procedures. Correcting restrictions is important even when the PA0613 pump itself requires replacement.

Inspect Wiring & Electrical Connections

If the Hoshizaki PA0613 does not operate when expected, technicians should verify the electrical circuit before replacing the pump assembly.

Inspect for:

• Correct electrical supply when the pump is commanded
• Loose electrical terminals
• Damaged connectors
• Broken wiring
• Corrosion
• Heat-damaged insulation
• Moisture contamination
• Control-circuit problems

An external wiring or machine-control problem should be corrected before a replacement pump is energized.

Technician Checks Before Ordering

Before replacing the Hoshizaki PA0613 water pump assembly, verify:

• OEM part number PA0613
• Complete Hoshizaki machine model
• Equipment serial number
• Auxiliary code where applicable
• Original pump identification
• Equipment electrical requirements
• Electrical connector configuration
• Pump mounting arrangement
• Water inlet configuration
• Water outlet configuration
• Original plumbing arrangement
• Pump orientation
• Associated wiring
• Condition of surrounding water-system components
• Signs of scale, restriction, leakage, or electrical damage

OEM part-number verification should be the primary identification method. Commercial ice-machine water pumps can look similar while having different electrical characteristics, water connections, flow characteristics, mounting configurations, and machine applications.

Inspect Related Water-System Components

When servicing the Hoshizaki PA0613, technicians should inspect related components that can affect water circulation and ice production.

Depending on the machine configuration, related areas may include:

• Water inlet valve
• Water reservoir
• Float switch or water-level control
• Water tubing
• Water-distribution components
• Water filter
• Drain system
• Electrical controls
• Associated wiring and connectors

Evaluating the complete water system helps reduce repeat service calls caused by replacing one component without correcting the underlying problem.

Commercial Ice Machine Applications

Compatible Hoshizaki equipment using the PA0613 water pump is commonly installed in demanding foodservice environments including:

• Restaurants
• Bars
• Hotels
• Supermarkets
• Convenience stores
• Schools
• Hospitals
• Universities
• Institutional kitchens
• Corporate cafeterias
• Catering operations
• Commercial foodservice facilities

Installation & Service Notes

Disconnect electrical power and follow applicable Hoshizaki service procedures before servicing commercial ice-making equipment. Shut off the water supply where required by the repair procedure.

Before removing the original PA0613 pump, document its electrical connections, water connections, mounting arrangement, pump orientation, and relationship to surrounding water-system components.

Compare the replacement pump assembly with the original component before installation. Inspect connected tubing and water passages for scale, debris, restrictions, or physical damage.

After installation, restore the equipment to operation and observe the applicable water-circulation and ice-making sequence.

Verify that:

• The pump starts when commanded
• Water circulates normally
• Water distribution is consistent
• No abnormal pump noise is present
• No excessive vibration occurs
• No water leaks are present
• Electrical connections remain secure
• The machine proceeds through its normal operating sequence

Commercial ice-machine water and electrical components should be diagnosed and installed by qualified foodservice-equipment service personnel.

Why Correct Hoshizaki OEM Pump Identification Matters

Commercial ice-machine water pumps can appear nearly identical while having different electrical requirements, flow characteristics, electrical connectors, plumbing connections, mounting configurations, and machine applications.

Using Hoshizaki OEM part number PA0613 together with the verified equipment model provides technicians and purchasing departments with strong identification points when comparing the replacement with the original pump.

Always verify the complete machine model, serial number, auxiliary code where applicable, original pump, electrical requirements, water connections, mounting arrangement, and applicable Hoshizaki service information before ordering.

Frequently Asked Questions

What is Hoshizaki PA0613?

Hoshizaki PA0613 is an OEM water pump assembly used in compatible Hoshizaki commercial ice machines.

Which Hoshizaki models use the PA0613 water pump?

The PA0613 is listed for compatible B-500PF, B-700PF, KM-340, KM-500, KM-501, KM-515, KM-630, KM-650, KM-900, KM-901, KML-600, KMS-830, and URC-12F equipment, including the complete model configurations listed above.

Does Hoshizaki PA0613 fit KM-340 ice machines?

It is listed for compatible KM-340MAH, KM-340MWH, and KM-340MWJ equipment. Verify the complete model, serial number, and auxiliary code before ordering.

Does Hoshizaki PA0613 fit KM-500 and KM-501 equipment?

It is listed for compatible KM-500MAH, KM-500MRH, KM-500MWH, and KM-501MWH machines.

Does Hoshizaki PA0613 fit KM-515 ice machines?

It is listed for compatible KM-515MAH, KM-515MAJ, KM-515MRH, KM-515MRJ, KM-515MWH, KM-515MWH-P, and KM-515MWJ equipment.

Does Hoshizaki PA0613 fit KM-650 equipment?

It is listed for compatible KM-650MAH, KM-650MRH, KM-650MRJ, and KM-650MWJ machines.

Does Hoshizaki PA0613 fit KM-900 and KM-901 ice machines?

It is listed for compatible KM-900 and KM-901 configurations shown above, including MAH, MRH, MWH, MRH3, and -P versions where listed.

Can a bad PA0613 pump cause a Hoshizaki ice machine not to make ice?

Yes. Inadequate water circulation can interfere with proper ice formation and normal machine operation. Other water-system and refrigeration conditions should also be evaluated.

Why is there water in my Hoshizaki ice machine but no circulation?

Possible causes include pump failure, missing electrical supply, damaged wiring, a restricted pump inlet or outlet, scale buildup, debris, or another water-distribution restriction.

Can the PA0613 pump run but still have poor flow?

Yes. A pump may operate while providing insufficient circulation because of mechanical wear, scale, debris, restrictions, low water level, or another water-system condition.

Can scale damage the Hoshizaki PA0613 water pump?

Scale and mineral deposits can restrict water passages and interfere with normal pump operation. The surrounding water system should also be inspected and maintained.

How do I confirm Hoshizaki PA0613 is the correct replacement?

Verify OEM part number PA0613, the complete Hoshizaki machine model, serial number, auxiliary code where applicable, original pump, electrical connection, water connections, mounting configuration, and applicable service documentation before ordering.

Is professional installation recommended?

Yes. Commercial ice-machine water and electrical components should be diagnosed and installed by qualified foodservice-equipment service personnel.
